Heavy Duty Bottle Filling Trough With Frame
Heavy Duty Bottle Filling Trough With Frame
Product Code: BF915-FRAME
No documents uploaded.
Description
- Model BF915-FRAME is a bottle filling trough mounted on a frame with shelf, constructed from grade 304 stainless steel, 1.6mm thick
- Available with 4 or 5 vandal resistant heavy duty bottle filling spouts (TVS9091SCBTFS)
- Cost effective solution for providing multiple bottle filling stations rather than individual bottle filling stations
- Flat pack frame and shelf for easy assembly on site
- This trough is suitable for freestanding use or alternatively can also be fixed to the back wall for extra rigidty
- The shelf has rear cutouts to allow for water and waste pipes to be routed through the shelf
- Wall mounted model without frame also available (BF915)
- To maintain the correct operation and extend the lifespan of this unit, a Y-strainer must be included in the water supply system. The Y-strainer plays a critical role in safeguarding internal parts and preserving the tap’s intended flow performance. Please note that not installing a Y-strainer will void the warranty.
Includes
- Flat pack stainless steel frame with legs and shelf
- Integral wall mounting points
- Centre 38mm flush grated waste fitting included (no plug or overflow)
Delivery
- Limited stock available, usually 1 to 3 working days
Dimensions
This bottle filling trough can be supplied at different lengths to accommodate 4 or 5 bottle filling spouts
- Lengths available: 1800mm (4 bottle filling spouts) | 2400mm (5 bottle filling spouts)
- Height: 150mm
- Front to back: 400mm
- Rear upstand: 75mm
- Tap Ledge: 70mm
- Height from floor: 850mm to wash trough rim
Where can this be installed?
- This bottle filling trough is ideal for locations where multiple users require bottle filling facilities at the same time
- Ideal for schools, colleges, factories, gyms etc. where no wall space is available in areas where bottle filling facilities are required
- Can be installed inside or outside
Optional Extras
- LARGE-PLASTIC-BOTTLETRAP – 1.5" plastic bottle trap
- LARGE-CHROME-BOTTLETRAP – 1.5" chrome plated bottle trap
- TVS364116 - Y strainer double check valve
FOR ANY ENQUIRIES OR QUOTES PLEASE CALL US ON 01452 721211 OR SEND US AN EMAIL TO [email protected]
