Press Button Temperature Control Tap

Press Button Temperature Control Tap

Product Code: TVS9007

  • Press Button Temperature Control Tap
  • Press Button Temperature Control Tap

No documents uploaded.

Specification
- Model TVS9007 is our non-concussive tap with adjustable temperature control
- Monobloc press button mixer tap
- Chrome plated brass body and head
- Self closing between 8 and 12 seconds
- WRAS approved
- Automatic closing for water saving
- 3 litre per minute flow rate to save water
- Lever to increase or decrease the temperature
- Supplied as a single tap with hot and cold water supply
- WRAS approved flexible inlet pipes
- Requires single 35mm tap hole

Technical Specification
- Max inlet pressure 6 bar
- Min inlet pressure 0.5 bar
- Timed flow (standard) 12 seconds at 1 bar
- Max inlet temperature 80 degrees C
- Flow rate 3 litres per minute

Delivery
- From stock, usually 1 to 3 working days

Optional Extra
TVS7001TMV3-15 - thermostatic mixing valve
TVS364116 - Y strainer double check valve

FOR ANY ENQUIRIES OR QUOTES PLEASE CONTACT US ON 01452 721211 OR SEND US AN EMAIL TO [email protected]
